Corning Cable FREEDM Loose Tube Gel-Free Single-Mode Plenum Cable


(Model # 048EWP-T4101DA3)
Corning FREEDM Loose Tube Gel-Free Single-Mode Plenum Cable
Corning
Image Shown is 24-Fiber Count

Note: Picture may not represent the actual product. We are continuously working on improving our website and reserve the right to change specifications, availability, and pricing without prior notice.


FREEDM Loose Tube Gel-Free Plenum Cable are flame-retardant, indoor/outdoor, plenum-rated cables suitable for installation in inter- and intrabuilding backbones in aerial, duct and riser or plenum applications.
Plenum Cable Features:
  • Loose Tube design offers mechanical ruggedness and environmental durability while the all-dielectric cable construction requires no grounding or bonding
  • Water-swellable yarn eliminates the need for gel-filling compound and allows more efficient and craft-friendly cable preparation
  • The flexible, flame retardant outer jacket is UV resistant and enables direct exposure to sunlight
  • Cable has Interlocking Armor for special applications requiring additional mechanical durability
  • The plenum rating of this cable eliminates the need to transition splice when entering the building and minimizes routing restrictions once inside the building
  • Color-coded 250 µm Fibers (12 Fibers per Tube)
  • Single-Mode Fiber Code, ITU 652.D Compliant
  • Wavelength: 1310/1383/1550 nm
  • Maximum Attenuation: 0.4/0.4/0.3 dB/km
  • Plenum Outer Jacket
  • Cable Marking Lengths are in Feet
  • Nominal Cable Weight: 86 lb/1000 ft
  • Nominal Outside Diameter: 0.44"
  • Maximum Tensile Load, Short-Term: 600 lbf
  • Maximum Tensile Load, Long-Term: 180 lbf
  • Minimum Bend Radius, Loaded: 6.6"
  • Minimum Bend Radius, Installed: 4.4"
  • Meeting the requirements of the National Electric Code (NEC) Article 770 - The cables are also OFNP and FT-6 listed and Meet Burn Test Criteria
  • Design and Test Criteria: ANSI/ICEA S-104-696; NFPA 262 (for Plenum, Riser and General Building Applications)
  • Available Fiber Counts: 24, 36, 48, and 60
Minimum Order Quantity is 2624 Feet. Larger amounts of Cable may be ordered. Please contact our Sales Department if needed.

Display all product SKU information
$18,774.45

Availability:
Usually ships in 3 weeks

Options
Fiber Count
Minimum Length
Metal Costs Rapidly Changing
Cable pricing is subject to change. You will be contacted if necessary.
Shipping Costs
Additional shipping charges may apply based on shipping insurance.

Qty:
